H1
|
41 mm
|
Height of outer ring above corrugated washer
|
Da max
|
36 mm
|
Maximum diameter of housing shoulder
|
da min
|
22 mm
|
Shaft shoulder minimum diameter
|
C
|
16 mm
|
outer ring width
|
D1
|
35 mm
|
Shaft ring split diameter
|
D2
|
24 mm
|
Long corrugated washer with diameter
|
D3
|
34 mm
|
Long Corrugated Washer Diameter
|
B
|
7.5 mm
|
Inner ring width
|
B1
|
20.5 mm
|
Long Wave Washer Width
|
B2
|
11 mm
|
Long Wave Washer Width
|
r min
|
0.3 mm
|
Minimum chamfer size
|
r1 min
|
0.6 mm
|
Minimum chamfer size
|
